Tengu 4025HT / 1190kV (6S)

Hand-wound EGODRIFT Tengu 4025HT motor for the Kraken 580 and other 6S high-kV setups in the 550-600mm class. The motor comes with a kV rating of 1190kV and features a modified base for yet improved cooling and performance.


$259.99
SKU: 11865
In stock
Details

EGODRIFT Tengu high-performance brushless motors for RC heli are the result of years of testing and development. The 4025HT comes with a kV rating of 1190kV for 6S LiPo batteries and is the perfect choice for your SAB Goblin Kraken 580 and other high-kv-550mm sized helicopter model.

Like all models within the Tengu series, the top of the can features the iconic and heat-resistant EGODRIFT Stickerbomb design, to add the finishing touch to your 550 class heli build.

Each motor comes with mounting screws and an (optional) screw for additional securing of the bell.

Please note:Due to the modified base (see diagram) the 4025HS shaft kits will NOT fit the new 4025HT motors! The available 6x32mm shaft for the 4025HT will fit the Kraken 580.

EGODRIFT Tengu 4025HT Series Product Dimensions
Specifications
  • Manufacturer: EGODRIFT
  • Stator size: 4025
  • Motor configuration: 12N10P
  • Wire colour: Copper
  • Motor wire type: High temperature copper wire
  • Motor wire: 1.5mm
  • Motor kV: 1190 kV
  • Motor shaft: Hardened Steel
  • Shaft diameter: 6.0 mm
  • External shaft length (mm): 32 mm
  • Mounting hole pattern: 2xM4(30) + 2xM3(25)
  • Laser Design: EGODRIFT Stickerbomb
  • LiPo cells: 6S
  • Stator diameter: 40 mm
  • Stator height: 25 mm
  • Stator lamination: 0.15 mm (+)
  • Body Length: 52.5mm (2.07 inch)
  • Diameter: 49.6mm (1.95 inch)
  • Idle current: TBD
  • Maximum Current: TBD
  • Maximum Power: TBD
  • Internal resistance: TBD
  • Connection: Wire / Gold plated plugs
  • Designer: Yutao Zou

What's in the box

  • 1 x Tengu 4025HT / 1190kV Motor (6x32mm shaft)
  • 3 x Gold Plated Connector, Male
  • 3 x Gold Plated Connector, Female
  • 4 x Mounting Screws
  • 1x Bell securing screw
User Images

Upload your own photo(s) of this product to show your skills and earn extra Bonus Points!

See More

Reviews
    • Verified Review

    Fits F3C machine with 670mm blades on 6s

    Not only designed for 3D, the Tengu 4025HT/1190 fits perfectly my RVE Phecda F3C machine with 670mm blades

    Review by Luisos
